8-Port 10/100Mbps PoE Switch

  • - IEEE 802.3at/af Power over Ethernet PoE compliant.
    - 8*10/100Mbps Auto-MDIX PoE ports, 1*10/100Mbps uplink port.
    - Each port support auto-negotiation-10/20, 100/200Mbps (Fast Ethernet).
    - Internal Power Supply.
    - Provides up to 30watts for single PoE port.
    - Automatically detects the PoE class level of a Powered Device.
    - LED indicators for monitoring power, link,activity and speed.
    - The VLAN slide switch allows to enable VLAN function by one-key.
    - Supports IEEE802.3ax flow control for Full Duplex and back-pressure for Half Duplex mode.
    Standards  IEEE 802.3af, IEEE 802.3at
      IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab
    Interface  8*10/100Mbps auto-negotiation PoE Ports, 1*uplink port
    Power Supply  AC100-240 V, 50/60 Hz
      Input: 52V/2.9A with Internal Power
    Basic Function  Standard IEEE 802.3at/af power supply
      Output power up to 30W/port
      One-key VLAN function enabled
      Professional lightning protection 4KV
      Power and data transmission up to 150m
    MAC Address Learning  Auto-learning, auto-aging
    MAC Address Table  4K
    Network Media  10Base-T: UTP Cat 3, 4, 5 cable (100m, max.)
      EIA/TIA-568 100Ω STP (100m max.)
      100Base-Tx: UTP Cat 5, 5e cable (100m, max.)
      EIA/TIA-568 1100Ω STP (100m max.)
    Backup Bandwidth  1.8Gbps
    Transmission Method  Store-and-forward
    LED  1* Power, 8*PoE LINK /Act, 1*Uplink LINK /Act
    Dimensions(L x W x H)  11.8 x 7.1 x 1.7 in. (300 x 180 x 44mm)
    Package Contents  SW2009P PoE Switch *1
      Ethernet Cable *1
      Quick Installation Guide *1
    Environment  Operating Temperature: 0℃~40 ℃ (32 ℉~104℉)
      Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)
      Operating Humidity: 10%~90% non-condensing
      Storage Humidity: 5%~90% non-condensing
