NR3000X

5G Wi-Fi6 Wireless CPE

  • - 5G to Wi-Fi
    - 3000Mbps Ultra-Fast Wi-Fi Speed
    - 5G NR Technology
    - The Latest Wi-Fi6 , Fast Wi-Fi Speed
    - 160MHz high bandwidth
    - 3000Mbps Ultra-Fast Wi-Fi Speed
    - Full Giga Ethernet Ports
    - Loop antennas layout, signal always online
  • Overviews
  • Features
  • Design
  • Tech Specs
  • Download
  • FAQs
    • - Complies with the next generation 3GPP Release 15 NSA/SA operation 5G NR technology and  the next generation Wi-Fi 6(IEEE 802.11ax) standard
    - 5G NR 5G NR transmission rate is 10X faster than the 4G CAT4 rate.
    - Simultaneous 2404Mbps on 5GHz and 574Mbps on 2.4GHz for a total of 3000Mbps.
    - Portable 5G/4G Wi-Fi Hotspot brings great convenience to users.
    - Plug an Ethernet cable into the LAN/WAN port for flexible access as a backup option if you can't get a 4G connection.
    - MU-MIMO technology allows data transmission to multiple devices at the same time.
    - Three gigabit ports ensure high speed wired and wireless connection.
    - Intuitive Web UI and APP ensures quick and simple installation.
    - Support Max.64 devices simultaneously.
    Hardware
    Interface
    - 2*1000Mbps LAN Ports
    - 1*1000Mbps WAN Port
    - 1* Standard SIM card slot
    - 1*DC/IN
    Power Supply
    - 12V DC/2A
    Antenna
    - 4 * internal 5G NR antennas
    - 2 * internal Dual-Band Wi-Fi antennas
    Button
    - 1*Reset button
    - 1*WPS button
    - 1*Power button
    LED  Indicators
    		 - 1*SYS(Red/Blue)
    - 1*WAN(RJ45 build-in)
    - 1*LAN(RJ45 build-in)
    Dimensions (L x W x H)
    - 120 x 180 x 256mm
    Wireless
    Standards
    - IEEE 802.11ac
    - IEEE 802.11n
    - IEEE 802.11g
    - IEEE 802.11b
    - IEEE 802.11a
    RF Frequency
    - 2.4GHz/5GHz
    Data Rate
    - 2.4GHz: Up to 574Mbps
    - 5GHz: Up to 2402Mbps
    EIRP
    - 2.4GHz < 20dBm
    - 5GHz < 20dBm
    Wireless Security
    - 64/128-bit WEP, WPA, WPA2 and WPA-Mixed
    - WPA3
    Reception Sensitivity  - 2.4G:11b 11M：-85 dBm@8% PER
               11g 54M：-72 dBm@10% PER
               11n  HT20 MCS7：-68dBm@10% PER
                      HT40 MCS7：-65dBm@10% PER
    - 5G:11a 54M：-72dBm@10% PER
            11n  HT20 MCS7：-68dBm@10% PER
                  HT40 MCS7：-65dBm@10% PER
            11ac VHT80 MCS9：-55dBm@10% PER
    5G NR
    5G NR chip
    - Makalu Ivy510
    NR&LTE Network Type and Band


    		 - 5G NR: N1,N20,N28,N41,N77,N78,N79
    - LTE FDD:  B1,B3,B5,B8
    - LTE TDD: B34,B38,B39,B40,B41
    - WCDMA: B1,B8

    Software
    Home


    - Quick Setup
    - Basic setup
    - Advanced setup
    - Logout
    - Reboot
    Network

    - WAN Setting
    - LAN Setting
    - IP/MAC Binding
    - DDNS Setting
    - IPTV Setting
    - IPv6
    WAN Type
    - Static IP, DHCP, PPPoE, 5G/4G
    Wireless
    - Basic setup
    - Parental Control
    QoS
    - Up/Down speed control on WAN, Bandwidth control based on IP address
    Security


    - MAC Filtering
    - IP/Port Filtering
    - URL Filtering
    NAT
    - Virtual Server(Port Forwarding)
    - DMZ
    - VPN passthrough
    Tools

    		 - Upgrade Firmware
    - Time Setup
    - Remote management
    - Password Settings
    - Reboot Schedule
    - System Log and so on

    Others
    Package Contents

    - 5G Wi-Fi6 Wireless CPE
    - Quick Installation Guide
    - Power Adapter
    - Ethernet Cable
    - Micro/Nano to Standard SIM Card Adapter
    Environment

    		 - Operating Temperature: 0℃~40℃ (32℉ ~104℉)
    - Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉)
    - Operating Humidity: 10%~90% non-condensing
    - Storage Humidity: 5%~90% non-condensing
